ICR-2701 is the enhanced successor of Advantech´s LAN router platform v2 which was originally introduced in 2010. Ruggedized for industrial use keeping the same dimensions, configuration possibilities, and full operating system compatibility with Advantech cellular routers including support of software platforms WebAccess/VPN and WebAccess/DMP.
ICR-2701 offers a more powerful CPU and amply of data storage to ensure a long lifecycle (software updates) with broad software customization possibilities for users. The router has also a TPM 2.0 chip (Trusted Platform Module) onboard verifying router integrity to provide a trusted solution as a response to increasing cybersecurity demands in many industrial and public sectors. LAN router ICR-2701 is equipped with 2 × Ethernet 10/100 ports with two independent LANs/IP addresses and 1 × USB 2.0 host port. Optional built-in WiFi 802.11 ac,a,b,g,n with AP, Client and Multirole modes are available.
The router is powered by well-known Linux-based Advantech´s operating system ICR-OS.
A secure web interface allows users to configure and manage ICR-2701 from remote locations. ICR-2701 supports real-time data encryption and establishing of VPN tunnels using IPsec, WireGuard, OpenVPN, GRE, etc. It supports standard and advanced networking features like DHCP, NAT, NAT-T, DynDNS, NTP, VRRP, and numerous other functions.
The 1.3 GB eMMC available storage for customers with an open Linux platform and the wide possibility of programming customer SW applications in Python and C/C++ ICR-2701 offers a real open development platform for Industrial IoT applications. Advantech existing Router App library (User modules) with apps already developed to enhance specific router functionalities includes industrial protocol conversions, dynamic protocols, and support of IoT platforms such as MS Azure, Cumulocity, and others.
ICR-2701 is easy to install individually and in mass deployments scenarios too by using a full-featured configuration and monitoring software tool WebAccess/DMP. Safe remote VPN access to customer devices and PCs connected to routers through Internet can be administrated by additional software WebAccess/VPN.
Using ICR-2701 in the industrial and non-industrial environments brings the key advantage in full compatibility with Advantech cellular routers where complete communication structure is unified and the same procedures and tools can be used for cellular and non-cellular parts of the application as well. LAN routers are frequently used as secure LAN to WAN gateways and VPN appliances in a large scope of monitoring and data acquisition systems.
Subscribe to all notifications for this product.
Datasheet_A4_ICR-2701_23072024_email.pdf
Advantech_Global_Cellular_Routers_Brochure_19062024.pdf | 3 MB
ICR-2701_Hardware_Manual_20240905.pdf | 5 MB | 05.09.2024
ICR-2[78]00_Configuration_Manual_20240529.pdf | 6 MB | 29.05.2024
ADVANTECH_CZECH_ISO_certificate_EN_2024.PDF | 23.09.2021
POS-2024-015_ICR-2701_rev_2_0_DoC_CE_240202.pdf | 05.02.2024
POS-2024-018_ICR-2701_rev_2_0_DoC_UKCA_240202.pdf | 05.02.2024
POS-2024-082_RoHS.pdf | 19.09.2024
POS-2024-083_REACH.pdf | 19.09.2024
POS-2024-084_WEEE.pdf | 19.09.2024
Firmware_Compatibility_Chart_20240816.pdf | 286 KB
Release_Notes_6.4.3.pdf | 188 KB
icr-270x.zip | 19 MB
Firmware_Compatibility_Chart_20240529.pdf | 286 KB
Release_Notes_6.4.2.pdf | 237 KB
icr-270x.zip | 19 MB
Firmware_Compatibility_Chart_20240327.pdf | 246 KB
Release_Notes_6.4.1.pdf | 192 KB
icr-270x.zip | 18 MB
Firmware_Compatibility_Chart_20240207.pdf | 251 KB
Release_Notes_6.4.0.pdf | 228 KB
icr-270x.zip | 18 MB
Firmware_Distribution_Overview_20230505.pdf | 249 KB
icr-270x.zip | 16 MB
release-notes-6.3.10.pdf | 267 KB
Firmware_Distribution_Overview_20230104.pdf | 248 KB
icr-270x.zip | 16 MB
release-notes-6.3.9.pdf | 328 KB
firmware-distribution-overview-20221202.pdf | 246 KB
icr-270x.zip | 16 MB
release-notes-6.3.8.pdf | 401 KB
ICR_270x.zip | 16 MB
firmware-distribution-overview-20220927.pdf | 241 KB
release-notes-6.3.7.pdf | 383 KB
firmware-distribution-overview-20220420.pdf | 185 KB
icr_270x.zip | 16 MB
release-notes-6.3.5.pdf | 805 KB
ICR-2701_Metal_000.png | 989 KB
ICR-2701_Metal_001.png | 703 KB
ICR-2701_Metal_003.png | 831 KB
ICR-2701_Metal_WiFi_000.png | 1003 KB
ICR-2701_Metal_WiFi_001.png | 720 KB
ICR-2701_Plastic_000.png | 1 MB
ICR-2701_Plastic_001.png | 809 KB
ICR-2701_Plastic_003.png | 1 MB
ICR-2701_Plastic_WiFi_000.png | 1 MB
ICR-2701_Plastic_WiFi_001.png | 815 KB
PCN-2023-07_Unique_EAN_Codes.pdf | 29.08.2023
PCN-2023-10_ICR-2[78]00_Rev.2.0.pdf | 15.11.2023
PCN-2024-01-01_BB-AW-A2458G-FSRPK_EoL.pdf | 03.07.2024
PCN-2024-02_Default_Password_Change.pdf | 05.08.2024
PCN-2024-03_WebAccessDMP_Gen3_Client.pdf | 14.08.2024
Security Guidelines 20240126.pdf | 26.01.2024
WireGuard 20220908.pdf | 09.09.2022
Commands_and_Scripts_20240821.pdf | 21.08.2024
VLAN 20220908.pdf | 09.09.2022
FlexVPN 20220908.pdf | 01.12.2022
Remote_Monitoring 20220908.pdf | 09.09.2022
IPsec Tunnel 20220908.pdf | 09.09.2022
Router_Features_20240412.pdf | 12.04.2024
PCI DSS Compliance Considerations 20220908.pdf | 09.09.2022
SNMP Object Identifiers 20240322.pdf | 22.03.2024
Quality of Service QoS 20220908.pdf | 09.09.2022
AT commands 20220908.pdf | 09.09.2022
Advantech Routers Watchdog Concept 20220908.pdf | 09.09.2022
Programming_of_Router_Apps_20240409.pdf | 09.04.2024
GRE Tunnel 20230202.pdf | 02.02.2023
OpenVPN Tunnel 20231214.pdf | 14.12.2023
MTBF_report_ICR-2701.pdf | 23.10.2023
MTBF_report_ICR-2701W.pdf | 23.10.2023
